SCH10-SCH160 A403 ASME B16.9 316L Stainless Weld Fittings Lap Joint Stub End

Ask Lasest Price
Brand Name :	YUHAO
Model Number :	Butt Weld Pipe Fittings
Certification :	ASTM, AISI, GB, DIN, JIS,EN
Price :	Negotiation
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :	15days
Supply Ability :	2000tons/per month

Add to Cart

Product Details
Company Profile

SCH10-SCH160 A403 ASME B16.9 316L Stainless Weld Fittings Lap Joint Stub End

SCH10-SCH160 A403 ASME B16.9 316L Stainless Weld Fittings Lap Joint Stub End

►Products description

The Stainless Butt Weld Fittings Lap Joint Stub End (A403 F316L/316 Sch 10 1/2") is designed for high-performance industrial applications, offering exceptional corrosion resistance and durability. Made from premium F316L/316 stainless steel, it complies with A403 standards, ensuring reliability in high-pressure and high-temperature environments. The lap joint stub end design allows for easy alignment and disassembly, making it ideal for use with lap joint flanges in chemical, petrochemical, and oil & gas industries. Precision-engineered for leak-proof connections, this fitting guarantees seamless integration and long-term performance in demanding piping systems. A trusted solution for critical applications, it delivers superior quality and reliability under extreme conditions.

►Product Size

DN	NPS	OD	Nominal Wall Thickness
DN	NPS	OD	Schss	Sch10S	Sch405	Sch8os	Sch10	Sch20	Sch30	STD	Sch40	Sch60	XS
6	1/8	10.3	-	1.24	1.73	2.41	-	-	-	1.73	1.73	-	2.41
8	1/4	13.7		1.65	2.24	3.02	-	-	-	2.24	2.24	-	3.02
10	3/8	17.1	-	1.65	2.31	3.2	-	-	-	2.31	2.31	-	3.2
15	1/2	21.3	1.65	2.11	2.77	3.73	-	-	-	2.77	2.77	-	3.73
20	3/4	26.7	1.65	2.11	2.87	3.91	-	-	-	2.87	2.87	-	3.91
25	1	33.4	1.65	2.77	3.38	4.55	-	-	-	3.38	3.38	-	4.55
32	1 1/4	42.2	1.65	2.77	3.56	4.85	-	-	-	3.56	3.56	-	4.85
40	1 1/2	48.3	1.65	2.77	3.68	5.08	-	-	-	3.68	3.68	-	5.08
50	2	60.3	1.65	2.77	3.91	5.54	-	-	-	3.91	3.91	-	5.54
65	2 1/2	73	2.11	3.05	5.16	7.01	-	-	-	5.16	5.16	-	7.01
80	3	88.9	2.11	3.05	5.49	7.62	-	-	-	5.49	5.49	-	7.62
90	3 1/2	101.6	2.11	3.05	5.74	8.08	-	-	-	5.74	5.74	-	8.08
100	4	114.3	2.11	3.05	6.02	8.56	-	-	-	6.02	6.02	-	8.56
125	5	141.3	2.77	3.4	6.55	9.53	-	-	-	6.55	6.55	-	9.53
150	6	168.3	2.77	3.4	7.11	10.97	-	-	-	7.11	7.11	-	10.97
200	8	219.1	2.77	3.76	8.18	12.7	-	6.35	7.04	8.18	8.18	10.31	12.7
250	10	273	3.4	4.19	9.27	12.7	-	6.35	7.8	9.27	9.27	12.7	12.7
300	12	323.8	3.96	4.57	9.53	12.7	-	6.35	8.38	9.53	10.31	14.27	12.7
350	14	355.6	3.96	4.78	-	-	6.35	7.92	9.53	9.53	11.13	15.09	12.7
400	16	406.4	4.19	4.78	-		6.35	7.92	9.53	9.53	12.7	16.66	12.7
450	18	457	4.19	4.78	-	-	6.35	7.92	11.13	9.53	14.27	19.05	12.7
500	20	508	4.78	5.54	-	-	6.35	9.53	12.7	9.53	15.09	20.62	12.7

►Factroy Shoot

SCH10-SCH160 A403 ASME B16.9 316L Stainless Weld Fittings Lap Joint Stub End

►FAQ

Q1: Can we visit your factory?
A: Sure, we welcome you to visit our factory , check our production lines and know more about our strength and quality.

Q2: Can you make the product according to our requirements?
A: Yes, we will strictly follow your requirements, such as the way of the package, the length of the product,the treatment of the product and so on.

Q3: Can you arrange the shipment for us?
A: Yes, we have designated sea freight and railway freight forwarders with decades of experiences and we get the best price with earliest vessel and professional service.

Q4: Do you provide samples? is it free or extra?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q5: Which payment can you accept?
A: 30% T/T prepaid and the balance against the copy of B/L.
